OTC Universal Cylinder Liner Puller

OTC Universal Cylinder Liner Puller

Features and Benefits:

• Quickly removes heavy-duty cylinder liners
• Similar to Porta-Tool OE tool number : PT-6400-C
• Cylinder bore diameter: 3-7/8″ to 6-1/4″
• Liner wall thickness: 0.273″ min
• Sleeve depth: Up to 15″
• Vehicle applications:Mack,Volvo,Detroit,International,Cummins (except L10 and C series),Cat Engines 3176, 3196, 3300 Series, 3400 Series, 3500 Series, C10, C12, C15, C16,Maxxforce DT, DT360, DTA360, DTA466, DT466, DT530 (PLN), DT466E, DT530E, DT570, HT570

</span

Designed to be used with an impact wrench for quick cylinder liner removal. The spring loaded puller arms automatically adjust to fit the liner for a fast set-up time. The low profile of this tool allows work in areas where space is limited. The tool accommodates bore diameters from 3-7/8″ to 6-1/4″, sleeve depths to 15″, and liner wall thickness of 0.273″ min. Drive screw hex size; 1-1/8″. Works on select Mack, Volvo, Detroit Diesel, International, Cummins, Navistar and other Caterpillar engines. Similar to Porta-Tool OE tool number PT-6400-C.

Warranty: Lifetime warranty does not cover abuse
